Which battery and body versions does the eDELIVER5 offer?

The 2026 eDELIVER5 guide lists 50 kWh and 64 kWh batteries and a 120 kW/240 N·m drive motor. The L1H1 panel van measures 4,980×1,870×1,960 mm with 6.6 m³ of cargo volume; the L1H2 offers 7.6 m³, the L2H1 7.5 m³ and the L2H2 8.7 m³.

What is the payload of the eDELIVER5?

For the L1H1, the 50 kWh version has a payload of 1,260/1,300 kg for the two-seat/three-seat versions respectively, and the 64 kWh version 1,200 kg.

Are Specifications for All Four eDELIVER Models the Same Worldwide?

No. Model availability, bodies, batteries, equipment, certified payloads and range figures may vary by country or region. Ask a local authorised MAXUS dealer about specific body versions, specifications and availability, and follow local official specifications and the vehicle actually delivered.

eDeliver 5

View Full Specifications Global

64 kWh: Battery Capacity

335 km: MAX WLTP Range(combined)

1200 kg: Maximum Payload

Gallery

Every Angle, Every Detail

Discover the eDeliver 5 van inside and out — from its bold exterior to a cabin built around the driver.

Fast Cruise Control driving on road for eDeliver5

easy driving experience for artisan from eDeliver5

Side-opening door for easy loading from eDeliver5

Optimized flat seating for enhanced comfort

Versatile payload capacity up to 1200 kg

Designed To Inspire Comfort

Expansive cargo area up to 7.6 m³

Optimized flat seating for enhanced comfort

Ample cabin space for ease of movement

Versatile payload capacity up to 1200 kg

Robust 64 kWh battery for enduring journeys

335 km WLTP range for flexible operations

High-efficiency electric drive for eco-friendly transport
Superior energy management

Green Power for the Future

Robust 64 kWh battery for enduring journeys

335 km WLTP range for flexible operations

High-efficiency electric drive for eco-friendly transport

Superior energy management

360° Surround-view camera for comprehensive awareness

Autonomous Emergency Braking (AEB) for proactive safety

Lane Departure Warning to prevent unintentional drift

Full-speed Adaptive Cruise Control for stress-free driving on all road conditions

Advanced Safety Measures

360° Surround-view camera for comprehensive awareness

Autonomous Emergency Braking (AEB) for proactive safety

Lane Departure Warning to prevent unintentional drift

Full-speed Adaptive Cruise Control for stress-free driving on all road conditions

12.3-inch central touchscreen for intuitive control
Voice-controlled assistant for hands-free command

Wireless Apple CarPlay & Android Auto for hassle-free connectivity

Optinal Internet on Vehicle (IOV) functions for a connected and future-proof driving experience

Smart Connectivity Solutions

12.3-inch central touchscreen for intuitive control

Voice-controlled assistant for hands-free command

Wireless Apple CarPlay & Android Auto for hassle-free connectivity

Optinal Internet on Vehicle (IOV) functions for a connected and future-proof driving experience

Specifications

Specifications Of eDeliver 5 Van

Specification

VERSIONVAN FWD N1 L1H1 / 50 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)4980
Overall width without mirrors (mm)1870
Overall height (mm)1960
Wheelbase (mm)3100
Max. load volume (with bulkhead) (cu.m)6.6
WEIGHTS AND PAYLOAD
Max. GVM (kg)3040
Min.kerb mass (kg)*1740
Max.gross payload (kg)1300
Max. GTM (kg)4540
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）11.5
BATTERY AND CHARGING
Battery energy (kWh)50
WLTP Combined Range (km)**245
WLTP City Range (km)**349
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***3.5
High-powered DC charger (kW)***77
20-80% DC charging (mins)***25
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

Specification

VERSIONVAN FWD N1 L1H1 / 64 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)4980
Overall width without mirrors (mm)1870
Overall height (mm)1960
Wheelbase (mm)3100
Max. load volume (with bulkhead) (cu.m)6.6
WEIGHTS AND PAYLOAD
Max. GVM (kg)3050
Min.kerb mass (kg)*1850
Max.gross payload (kg)1200
Max. GTM (kg)4550
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）11.5
BATTERY AND CHARGING
Battery energy (kWh)64
WLTP Combined Range (km)**335
WLTP City Range (km)**489
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***4
High-powered DC charger (kW)***70
20-80% DC charging (mins)***36
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

Specification

VERSIONVAN FWD N1 L1H2 / 50 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)4980
Overall width without mirrors (mm)1870
Overall height (mm)2180
Wheelbase (mm)3100
Max. load volume (with bulkhead) (cu.m)7.6
WEIGHTS AND PAYLOAD
Max. GVM (kg)3040
Min.kerb mass (kg)*1740
Max.gross payload (kg)1300
Max. GTM (kg)4540
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）11.5
BATTERY AND CHARGING
Battery energy (kWh)50
WLTP Combined Range (km)**235
WLTP City Range (km)**340
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***3.5
High-powered DC charger (kW)***77
20-80% DC charging (mins)***25
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

Specification

VERSIONVAN FWD N1 L1H2 / 64 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)4980
Overall width without mirrors (mm)1870
Overall height (mm)2180
Wheelbase (mm)3100
Max. load volume (with bulkhead) (cu.m)7.6
WEIGHTS AND PAYLOAD
Max. GVM (kg)3050
Min.kerb mass (kg)*1850
Max.gross payload (kg)1200
Max. GTM (kg)4550
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）11.5
BATTERY AND CHARGING
Battery energy (kWh)64
WLTP Combined Range (km)**305
WLTP City Range (km)**467
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***4
High-powered DC charger (kW)***70
20-80% DC charging (mins)***36
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)O

Specification

VERSIONVAN FWD N1 L2H1 / 50 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)5430
Overall width without mirrors (mm)1870
Overall height (mm)1960
Wheelbase (mm)3450
Max. load volume (with bulkhead) (cu.m)7.5
WEIGHTS AND PAYLOAD
Max. GVM (kg)3130
Min.kerb mass (kg)*1820
Max.gross payload (kg)1310
Max. GTM (kg)4630
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）12.8
BATTERY AND CHARGING
Battery energy (kWh)50
WLTP Combined Range (km)**235
WLTP City Range (km)**332
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***3.5
High-powered DC charger (kW)***77
20-80% DC charging (mins)***25
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)O

Specification

VERSIONVAN FWD N1 L2H1 / 64 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)5430
Overall width without mirrors (mm)1870
Overall height (mm)1960
Wheelbase (mm)3450
Max. load volume (with bulkhead) (cu.m)7.5
WEIGHTS AND PAYLOAD
Max. GVM (kg)3195
Min.kerb mass (kg)*1930
Max.gross payload (kg)1265
Max. GTM (kg)4695
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）12.8
BATTERY AND CHARGING
Battery energy (kWh)64
WLTP Combined Range (km)**321
WLTP City Range (km)**454
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***4
High-powered DC charger (kW)***70
20-80% DC charging (mins)***36
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

Specification

VERSIONVAN FWD N1 L2H2 / 50 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)5430
Overall width without mirrors (mm)1870
Overall height (mm)2180
Wheelbase (mm)3450
Max. load volume (with bulkhead) (cu.m)8.7
WEIGHTS AND PAYLOAD
Max. GVM (kg)3130
Min.kerb mass (kg)*1820
Max.gross payload (kg)1310
Max. GTM (kg)4630
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）12.8
BATTERY AND CHARGING
Battery energy (kWh)50
WLTP Combined Range (km)**229
WLTP City Range (km)**320
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***3.5
High-powered DC charger (kW)***77
20-80% DC charging (mins)***25
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

Specification

VERSIONVAN FWD N1 L2H2 / 64 kWh

DIMENSIONS
Seating2/3
Slide doorSingle/Dual
Overall length (mm)5430
Overall width without mirrors (mm)1870
Overall height (mm)2180
Wheelbase (mm)3450
Max. load volume (with bulkhead) (cu.m)8.7
WEIGHTS AND PAYLOAD
Max. GVM (kg)3195
Min.kerb mass (kg)*1930
Max.gross payload (kg)1265
Max. GTM (kg)4695
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）12.8
BATTERY AND CHARGING
Battery energy (kWh)64
WLTP Combined Range (km)**301
WLTP City Range (km)**436
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***4
High-powered DC charger (kW)***70
20-80% DC charging (mins)***36
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

Specification

VERSIONCAB FWD N1 L2H0 / 50 kWh

DIMENSIONS
Seating2
Slide door—
Overall length (mm)5280
Overall width without mirrors (mm)1870
Overall height (mm)1960
Wheelbase (mm)3450
Max. load volume (with bulkhead) (cu.m)—
WEIGHTS AND PAYLOAD
Max. GVM (kg)3000
Min.kerb mass (kg)*1510
Max.gross payload (kg)1490
Max. GTM (kg)4500
Max.towing (Braked/Unbraked) (kg)1500/750
PERFORMANCE AND STEERING
Max. Power (kW)120
Max. Porque（Nm)240
Max.speed（km/h)120
Min.turning circle（m）12.8
BATTERY AND CHARGING
Battery energy (kWh)50
WLTP Combined Range (km)**141-201
WLTP City Range (km)**235-319
Onboard charger (kW)***11
20-80% AC charging-Onboard charger 3-phase tethered (hrs)***3.5
High-powered DC charger (kW)***77
20-80% DC charging (mins)***25
WHEELS AND TYRES
Wheels16-inch alloy wheel
Tyres195/65 R16
Window Package
Window Package (Privacy Glass)—

FAQ

FAQ For eDeliver 5

Get more detailed questions for eDeliver 5 van

Which battery and body versions does the eDELIVER5 offer?

The 2026 eDELIVER5 guide lists 50 kWh and 64 kWh batteries and a 120 kW/240 N·m drive motor. The L1H1 panel van measures 4,980×1,870×1,960 mm with 6.6 m³ of cargo volume; the L1H2 offers 7.6 m³, the L2H1 7.5 m³ and the L2H2 8.7 m³.
What is the payload of the eDELIVER5?

For the L1H1, the 50 kWh version has a payload of 1,260/1,300 kg for the two-seat/three-seat versions respectively, and the 64 kWh version 1,200 kg.
Are Specifications for All Four eDELIVER Models the Same Worldwide?

No. Model availability, bodies, batteries, equipment, certified payloads and range figures may vary by country or region. Ask a local authorised MAXUS dealer about specific body versions, specifications and availability, and follow local official specifications and the vehicle actually delivered.

Global Download Full Specification Sheet
